AMD Ryzen™ 5 4600G Desktop Processor

• General Specifications

  NameAMD Ryzen™ 5 4600G

  FamilyRyzen

  SeriesRyzen 4000 Series

  Form FactorDesktops , Boxed Processor

  Former CodenameRenoir

  ArchitectureZen 2

  # of CPU Cores6

  Multithreading (SMT)Yes

  # of Threads12

  Max. Boost Clock Up to 4.2 GHz

  Base Clock 3.7 GHz

  L1 Cache384 KB

  L2 Cache3 MB

  L3 Cache8 MB

  Default TDP65W

  AMD Configurable TDP (cTDP)45-65W

  Processor Technology for CPU CoresTSMC 7nm FinFET

  Package Die Count1

  Unlocked for Overclocking Yes

  CPU SocketAM4

  Supporting ChipsetsX570 , X470 , X370 , B550 , B450 , B350 , A520 , A320

  CPU Boost TechnologyPrecision Boost 2

  Instruction Setx86-64

  Supported ExtensionsAES , AMD-V , AVX , AVX2 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64

  Max. Operating Temperature (Tjmax)95°C

  Launch Date7/21/2020

  *OS SupportWindows 11 – 64-Bit Edition , Windows 10 – 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit

• Connectivity

  Native USB 3.2 Gen 2 (10Gbps) Ports4

  Native USB 3.2 Gen 1 (5Gbps) Ports0

  Native USB 2.0 (480Mbps) Ports0

  Native SATA Ports2

  PCI Express® VersionPCIe® 3.0

  Native PCIe® Lanes (Total/Usable)24 , 20

  Additional Usable PCIe Lanes from Motherboard

  X570

  16x Gen 3

  X470

  2x Gen 3, 8x Gen 2

  NVMe SupportBoot , RAID0 , RAID1 , RAID10

  System Memory TypeDDR4

  Memory Channels2

  Max. Memory128 GB

  System Memory SubtypeUDIMM

  System Memory SpecificationUp to 3200 MT/s

  Max Memory Speed

  2x1R

  DDR4-3200

  2x2R

  DDR4-3200

  4x1R

  DDR4-2933

  4x2R

  DDR4-2667

  ECC SupportNo

• Graphics Capabilities

  Graphics ModelRadeon™ Graphics

  Graphics Core Count7

  Graphics Frequency1900 MHz

  USB Type-C® DisplayPort™ Alternate ModeYes

• Product IDs

  Product ID Boxed100-100000147BOX

  Product ID Tray100-000000147

• Key Features

  Supported TechnologiesAMD StoreMI Technology , AMD Zen 2 Core Architecture , AMD Ryzen™ VR-Ready Premium
