DeskMini X600

• CPU
  – Supports AMD Socket AM5 Ryzen™ 8000/7000 Series Processors, Max. TDP 65W
• Chipset
  – AMD X600
• Cooler
  – Supports AMD AM5/AM4 CPU Cooler (Max. Height ≦ 47mm)
• Memory
  – Supports 2 x SO-DIMM DDR5-6400+(OC)MHz memory, Max. 96GB (non-ECC)
• Graphics
  – HDMI (4K@120Hz)
  – DisplayPort 1.4 (4K@120Hz)
  – D-Sub
• Audio
  – Realtek ALC269 Audio Codec
• Storage
  – 2 x SATA3 6Gb 2.5-inch 7mm/9.5mm Hard Drive
  – 1 x Blazing M.2 Socket (M2_1), support type 2280 PCIe Gen5x4 (128 Gb/s) mode*
  – 1 x Hyper M.2 Socket (M2_2), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode*

  *Supports NVMe SSD as boot disks
• RAID
  – Supports RAID 0 and RAID 1 for M.2 NVMe storage devices
• LAN
  – 2.5 Gigabit LAN (Dragon RTL8125BG)
• WLAN
  – 1 x M.2 Socket (Key E), supports type 2230 Wi-Fi/BT module
• Front I/O
  – 1 x MIC-In
  – 1 x USB 3.2 Gen1 Type-C Port (Supports ESD Protection)
  – 1 x USB 3.2 Gen1 Type-A Port (Supports ESD Protection)
  – 1 x Head Phone with MIC Jack
• Rear I/O
  – 1 x DC-In Jack (Compatible with the 19V power adapter)
  – 1 x D-Sub Port
  – 1 x HDMI Port
  – 1 x DisplayPort 1.4
  – 2 x USB 3.2 Gen1 Type-A Ports (Supports ESD Protection)
  – 1 x RJ-45 LAN Port with LED
• Connectors
  – 1 x USB 2.0 Header
  – 1 x Front Panel Header
  – 2 x 4-Pin fan connectors (CPU, SYS)
  – 1 x Internal Speaker Header (4-Pin)
  – 1 x Chassis Intrusion Header (2-Pin)
  – 1 x Audio Header (4-Pin)
• Accessory
  – 2 x SATA Data with Power Cable
  – 1 x 120W/19V adapter
  – 1 x Screws Pack
• Dimension
  – 155 x 155 x 80 mm (1.92L)
• OS
  – Microsoft^® Windows^® 10 64-bit / 11 64-bit

Powerful Processing Performance

ASRock DeskMini X600 supports the latest AMD Ryzen™ 8000 G-Series desktop processors. With up to 8 cores, 16 threads, these processors deliver ultimate performance for multitask computing compared with mobile processors. In addition, with AMD Ryzen™ 8000 G-Series desktop processors, you get the world’s fastest integrated graphics.

Insane DDR5 Memory Performance

DeskMini X600 supports Dual Channel DDR5-6400+MHz (OC) memory, up to 96GB. Thanks to high speed DDR5 memory and Radeon™ Graphics, DeskMini X600 provides awesome 3D performance.

Heatsink on MOSFET

ASRock DeskMini X600 features with Aluminum MOSFET Heatsink offering great heat dissipation to ensure system’s stability in daily computing.

4X Storages

ASRock DeskMini supports up to 4 Storages
M2_1 M.2 (2280) –PCIe Gen5 x4
M2_2 M.2 (2280) –PCIe Gen4 x4
2x 2.5” SATA 6Gb SSD/HDD Tray

Mini Home Data Center

DeskMini X600 supports RAID 0/1 function! Build mini data center at home!
RAID 0 –offers superior I/O performance
RAID 1 –protects critical data in mirrored data

2.5 Gb/s LAN

The intelligent 2.5Gb/s LAN platform is built for maximum networking performance for the demanding requirements of home networking, content creators, online gamers and high-quality streaming media. Boost networking performance up to 2.5X the bandwidth compared to the standard gigabit Ethernet, you’ll enjoy the faster and uncompromised connectivity experience for gaming, file transfers and backups.

Triple Display

Up to three displays can be used simultaneously. With multi-screen, you can have high productivity and immersive gaming experience.

USB Type-C

A Type-C USB 3.2 Gen1 connector for fast charging and delivering up to 5Gbps data transfer rates.

Auto Driver Installer

No need to worry about lack of disk drive! Asrock preinstall LAN driver to ensure that you are able to install all drivers needed in an easier way than using SCD.
step1: Install Auto Driver Installer
step2: Update drivers needed
step3: Done!

DeskMini Addressable LED(Optional)

Exclusive Addressable RGB LED Strip for ASRock DeskMini Series mini PC. Attach the magnetic strip inside the chassis to create cool personalized lighting for you.

* The availability of ARGB LED Strip may vary from model or region to another.



DeskMini USB Hub(Optional)

Attach the magnetic DeskMini USB Hub inside the chassis. Let you easy connect to the DeskMini Addressable LED and USB 2.0 Cable for fantastic personalized lighting as well as the accessibility to expand extra 2x USB 2.0 ports.

*The availability of DeskMini USB Hub may vary from model or region to another.



Rear Audio Cable(Optional)

Connect to external audio devices such as: 2.1 channel speaker, soundbar, headphone amplifier, and so on…

AMD APU Cooler(Optional)

AMD CPU Cooler provides superior thermal performance.
Dimension: 77 x 68 x 45 mm
Fan Speed: 1950 ~ 3500 R.P.M

*The availability of APU Cooler may vary for different models & regions.

VESA Mount Kit(Optional)

ASRock VESA Mount Kit of DeskMini lets you attach your DeskMini to any VESA-compatible wall mount, monitor or articulating arms to create your ideal space.

Intel^® Wi-Fi Kit (Optional)

ASRock M.2 Wi-Fi Kit includes Intel^® M.2 Wi-Fi module and two antennas; offering wireless connectivity for DeskMini.
Intel^® AX210 or Intel^® AC3168

The availability of M.2 Wi-Fi Kit may vary from model or region to another.

USB 2.0 Cable(Optional)

Purchasing USB Cable for extra 2 x USB 2.0 ports on DeskMini.
