Get high-performance cooling, display a favorite animated GIF or static image, monitor real-time PC performance metrics, see music that’s currently playing, stream browser content and more with NZXT CAM software.
- 2.36” diameter wide-angle LCD display with 640×640 resolution and 60 Hz refresh rate provides a sharp image from any viewing angle
- Screen supports the display of custom images, animated GIFs, and CAM system info with adjustable orientation
- Powerful Asetek pump provides optimal cooling and up to 2,800 RPM whisper-quiet operation
- Includes F140/F120 RGB Core fans
- Includes RGB Controller, RGB Fans, & USB Y-Cable
- Single breakout cable simplifies installation
- Rubber tubing is reinforced with nylon-braided sleeves to prevent leaks
- Control custom screen content, RGB, pump speed, and zero-noise fan curves with NZXT CAM software.
Inside the Box
-
Kraken Elite 360 RGB 1
-
F120 RGB Core fan 3
-
Installation Accessories 1
-
RGB Controller 1
-
Breakout cable set 1
Wide-Angle LCD Display
High-Performance Pump
Colorful Cooling
Installation Made Easy
- A single breakout cable from pump to motherboard streamlines installation.
- Includes compatible mounting brackets for Intel (LGA 1700/1200/115X) and AMD processors (AM4, AM5).
- Pre-applied NZXT High-Performance Thermal Paste.
- Extended rubber tubing with durable nylon-braided sleeves for worry-free handling.
Tech Specs
CAP
- Material:Aluminum, Plastic
- Display Orientation:Software adjustable Default, +90, +180, and -90 Degrees
- Display Panel Active Area:2.36” (60mm) diameter
- Display Color:24-bit true color LCD
- Display Resolution:640 x 640 px
- Display Brightness:690 cd/m²
- Display Panel Type:TFT-LCD (Wide Viewing Angle)
WATER BLOCK
- Dimensions:Diameter: 81.9mm H: 59.5mm
- Material (Block):Copper
- Material (Housing):Plastic
PUMP
- Motor Speed:800 – 2,800 ± 300 RPM
- Power:12V DC, 0.3A
RADIATOR
- Dimensions:121 x 394 x 27mm
- Material:Aluminum
TUBE
- Length:400mm
- Material:Ultra-low Evaporation Rubber with Nylon Braided Sleeve
FAN SPECS
- Model:F120 RGB Core Fans
- Quantity:3
- Dimension:120 x 120 x 26mm
- Speed:500-1,800 ± 180 RPM
- Airflow:78.86 CFM
- Air Pressure:2.57 mm H2O
- Noise:33.88 dBA
- Bearing:Fluid Dynamic Bearing
- Power Consumption:12 V DC, 0.2 A, 2.4 W
- Fan Connector:4-pin PWM
- Life:60,000 hours / 6 Years
- Limited Warranty:6 Years
RGB CONTROLLER
- Dimensions:63.2 x 53.2 x 12.8mm
- Weight:52.8g
- Mounting:Magnet and 3M Dual Lock
- Connection Cables:1x USB 2.0 internal connector 1x SATA power cable
- Input Connector:12V DC / 2.6A
- RGB Lighting Channels:3
- Output Channel Voltage:5V DC
- NZXT RGB Channel Output LED Qty.:Up to 40 LEDs per channel and up to 120 LEDs combined total for the total 3 channels
COMPATIBLE SOCKET & CPU
- Intel:Intel Socket LGA 1700, 1200/115X Intel Core i9 / Core i7 / Core i5 / Core i3 / Pentium / Celeron
- AMD:AMD Socket AM5, AM4, sTRX4*, TR4* (*Threadripper bracket not included) AMD Ryzen 9 / Ryzen 7 / Ryzen 5 / Ryzen 3 / Threadripper
